Product parameters

Designation Series	SC100	SC100/100	SC150	SC150/150	SC200	SC200/200	SC200E	SC200/200E	Note
Rate load(kg)	1000/ 12 person	2×1000/ 12 person	1500/ 18 person	2×1500/ 18 person	2000/ 24 person	2×2000/ 24 person	2000/ 24 person	2×2000/ 24 person
Erecting payload (kg)	800	2x800	900	2x900	1000	2x1000	1000	2x1000
Rated speed (m/min)	30	30	36	36	36	36	36	36
Reduction ratio	1:16	1:16	1:16	1:16	1:16	1:16	1:16	1:16
Max.lifting height(m)	150	150	250	250	250	250	250	250
Cage size(L×W×H) (m)	3.0×1.3×2.5	3.0×1.3×2.5	3.2×1.4×2.5	3.2×1.4×2.5	3.2×1.5×2.5	3.2×1.5×2.5	3.2×1.5×2.5	3.2×1.5×2.5
Power supply(V)	380V,50Hz or 60Hz	380V,50Hz or 60Hz	380V,50HZ or 60HZ	380V,50Hz or 60Hz	380V,50Hz or 60Hz	380V,50Hz or 60Hz	380V,50Hz or 60HZ	380V,50Hz or 60Hz
Motor power(kW)	2×11	2×2×11	2×13	2×2×13	3×11	2×2×11	2×13	2×2×13
Rated current (A)	2×24	2×2×24	2×27	2×2×27	3×24	3×2×24	2×27	2×2×27	JC=25%
Power capacity(KVA)	34	2×34	42	2×42	49	2×49	42	2×42
Mast section	Wall thickness of corner bar(chord member) (mm)			Weight of mast section(kg)			Dimension of mast section(m)
	T=4.5			142			0.65×0.65×1.508
	T=6.0			160
	T=8.0			180
	T=10.0			195
Cage weight (incl. driving system) (kg)	1750	2×1750	1820	2×1820	1950	2×1950	1950	2×1950
Safery device type	SAJ30-1.2	SAJ30-1.2	SAJ40-1.2	SAJ40-1.2	SAJ40-1.2	SAJ40-1.2	SAJ40-1.2	SAJ40-1.2
